D28 3D Welding Table

FIXTO D28 Series Welding Tables are made for the most Heavy-Duty Metal Fabrication Fixturing Applications. They truly are built to last a lifetime and beyond. The FIXTO, Indian-Engineered Welding Tables are extremely rigid and have the flattest surface of any Welding Table in the market, with a option of 5-Sided 3D and 1- Sided 2D welding tables which can be used with or without optional heavily constructed legs. The Nitride finish protects the welding table against rust and weld spatter to make sure that the Welding Tables surface is kept extremely clean and accurate for fixturing.

D28 3D Welding Table
Features:
  • D28 Hole separation=100±0.05mm
  • Stiffener base to ensure stability
  • Have 5 working surfaces
  • Surface hardness=20HRC
  • Flatness=0.3/1000mm
  • Verticality=0.1/200mm
  • Surface Roughtness=Ra3.2

Models

Add to My Fixture Model Width Depth Height
FIXTO-NCX-3015 3000 1500 850
FIXTO-NCX-2412 2400 1200 900/750
FIXTO-NCX-2010 2000 1000 900/750
FIXTO-NCX-1510 1500 1000 900/750
FIXTO-NCX-1212 1200 1200 900/750
FIXTO-NCX-1010 1000 1000 900/750
FIXTO-RCX-3015 3000 1500 900/750
FIXTO-RCX-2412 2400 1200 900/750
FIXTO-RCX-2010 2000 1000 950/750
FIXTO-RCX-1510 1500 1000 900/750
FIXTO-RCX-1212 1200 1200 900/750
FIXTO-RCX-1010 1000 1000 900/750
FIXTO-3D-NCZ-4020 4000 2000 900/750
FIXTO-3D-NCZ-3020 3000 2000 900/750
FIXTO-3D-NCZ-2020 2000 2000 900/750
FIXTO-3D-NCX-3010 3000 1000 900/750
FIXTO-3D-NCX-2115 2100 1500 900/750
FIXTO-3D-NCX-2015 2000 1500 900/750
